Features
Equipped with full servo control system to ensure the accuracy and stability of feeding, slotting, and bending function.
The double-slotting tool and the double-bend altermate bending setings make it easy to handle the processing of various materials.
The core hardware of the machine adopts the casting structure, which is fomed once and has strong stability.
Parameter Table
| No | Item | Data | |
| 1 | Motor | Japan Fuji servo motors (Four) | |
| 2 | Feeding system | Ball screw drived clamps | |
| 3 | Cutting system | Plane cutter and wheel cutter | |
| 4 | Min. bending angle | R6 | |
| 5 | Suitable material | Stainless steel, galvanized steel, aluminum, etc. | |
| 6 | Material thickness | 0.3-2mm (080") | |
| 7 | Material height | 15-200mm (8") | |
| 8 | Power | AC220V, 50/60Hz | |
| 9 | Files format | DXF. PLT | |
| 10 | Packing | Wooden box, 2.9CBM, 600Kg | |
 | Two mechanical clamping hands driven by high-quality double ball screws. Feeding system: fast and smooth | ||
 | Plane cutter and wheel cutter easily handle different kinds of material processing. High strength alloy cutters, long serve time. | ||
 | Double-bend alternately bending system, easily to make small angel sign letters. 750W powerful servo motor, equipped with Planet Reducer | ||
 | Stainless Steel, Galvanized Sheet, Aluminum flat, one edge aluminum profile and Luminous plastic | ||
