Application: remove solid slag and burrs on the surface of workpiece; remove rust and oxide layer on the surface of the workpiece; Round the internal and external contours at the edge of metal sheet.
Share:
Features
1. Application: remove solid slag and burrs on the surface of workpiece; remove rust and oxide layer on the surface of the workpiece; Round the internal and external contours at the edge of metal sheet.
2. Scope of workpiece: metal sheet cut by laser, fire, CNC stamping and punched
3. Suitable material: stainless steel, iron, aluminum and copper. Remove oxide skin, polishing and brushing are available.
4. Metal sheet maximum width: 1000mm
5. Polishing or brushing
Equipment Configuration and Related Technical Parameters
| Item | Parameters |
| Model | YZ1500G |
| Dimensions/Package | 1850*3300*2100mm, 5500KG |
| Material thickness | 0.2-80mm |
| Material width | 1500mm |
| Power supply | 380V/50Hz |
| Maximum power | 34.5KW |
| Compressed air | 0.6MPa |
| Conveying system | |
| Conveying method | Wear-resistant and heat-resistant rubber belt |
| Conveying speed | 0.5m-25m/min |
| Sanding system | |
| Sanding consumable | Abrasive belt -1020mm*2, (40, 80, 120, 240, 600mo) |
| Sanding roller speed | 1200r/min |
| Deburring system | |
| Deburring consumable | Emery cloth wheel*8 (300-300-32, (40, 80, 120, 240mo) |
| Main spindle speed | 0-1000r/min (Frequency speed) |
| Wheel alternating speed | 1-30r/min (Frequency speed ) |
| Rounding | R≤1mm |
| Workpiece fixed method | |
| Vacuum adsorption | 15kw, 2900r/min (1275*940*1400mm, 290KG) |
| Magnetic adsorption | High-intensity magnetic |
| Press roller | Four |
