Adaptable: can process all kinds of materials used in making sign letters, such as stainless steel, galvanized steel, flat aluminum, profile aluinum and channelume.
Customize for any other special aluminum profiles.
Rotatable: wheel cutter can turn around 360°to cut at front and back, at any angle.
Share:
Features
Adaptable: can process all kinds of materials used in making sign letters, such as stainless steel, galvanized steel, flat aluminum, profile aluinum and channelume.
Customize for any other special aluminum profiles.
Rotatable: wheel cutter can turn around 360°to cut at front and back, at any angle.
Parameter Table
| No | Item | Data | |
| 1 | Motor | Delta servo motors | |
| 2 | Feeding system | Ball screw drived clamps | |
| 3 | Cutting system | Plane cutter and rotated wheel cutter | |
| 4 | Min. bending angle | R6 | |
| 5 | Suitable material | Stainless steel, galvanized steel, aluminum flat, aluminum profiles, channelume, plastic, etc. | |
| 6 | Material thickness | 0.3-2mm (080") | |
| 7 | Material height | 15-200mm (8") | |
| 8 | Power | AC220V, 50/60Hz | |
| 9 | Files format | DXF. PLT | |
| 10 | Packing | Wooden box, 2.92CBM, 480Kg | |
 | Two mechanical clamping hands driven by high-quality double ball screws. Feeding system: fast and smooth | ||
 | Plane cutter for stainless steel, galvanized sheet;Rotated wheel cutter for all kinds aluminum profiles and channelume, plastic. High strength alloy cutters, long serve time. | ||
 | Double-bend alternately bending system, easily to make small angel sign letters. 750W powerful servo motor, equipped with Planet Reducer | ||
 | Stainless Steel, Galvanized Sheet, Aluminum flat, aluminum profile, channelume and Luminous plastic, etc. | ||
 | |||
